Diamant Zing Trip Core Midstep 2026
Diamant Zing Trip Core Midstep 2026
Diamant Zing Trip Core Midstep 2026
Diamant Zing Trip Core Midstep 2026
Diamant Zing Trip Core Midstep 2026
Diamant Zing Trip Core Midstep 2026

Diamant Zing Trip Core Midstep 2026

5330681

Regular price£2,825.00
/

Size
Colour
Battery

Found a better deal? Click here for our Price Match Promise.

View our shipping information Here.

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

The Zing Trip Core combines low weight with high performance and offers everything you need for everyday use and vacation. Thanks to the external battery, which can be easily removed for charging, storage, transport, and overnight stays, it is particularly practical. The well-thought-out equipment emphasizes the optimal price-performance ratio and is tailored to people who are interested in longer and dynamic trekking tours.

Frame High-performance hydroformed alloy, internal cable routing, external battery mount
Fork SR Suntour XCR32, coil spring, preload adjuster, lockout,100 mm QR, 63 mm travel
Wheels
Hub front Shimano Tourney HB-QC300, centerlock
Hub rear Shimano QC400, 32-hole, centerlock, 135x5 mm QR
Skewer rear 148x5 mm bolt-on
Rim Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Tyre Schwalbe G-One Allround, reflective strip, wire bead, puncture protection, 65-584
E-system
Charger Bosch standard 4A, 230V, smart system
*Computer Bosch Intuvia 100, smart system
Bosch LED remote, smart system
Motor Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Drivetrain
Shifter Shimano U4000, 9-speed
Rear derailleur Shimano CUES U4000
*Crank Size: S, M
ProWheel alloy, 165mm length
Size: L
ProWheel alloy, 170 mm length
Chainring Alloy, with 40T narrow-wide steel ring, alloy guard
Cassette Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain Shimano LG500, 9/10/11-speed
Pedal VP-536 nylon platform
Components
Saddle Selle Royal Vivo Moderate Ergo
*Seatpost Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Handlebar Ergotec Ergo Series XXL, 31.8 mm, 30 mm rise, 16 degree sweep
Grips Bontrager XR Endurance Comp, lock-on
*Stem Size: M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
*Brake Shimano MT200 hydraulic disc
*Brake rotor Shimano RT30, CentreLock, 180 mm
Shimano RT30, CentreLock, 180 mm
Weight
Weight M - 22.20 kg (400 Wh) / 23.00 kg (545 Wh) / 23.90 kg (800 Wh)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
