The Procaliber 9.6 is a race-ready cross country hardtail made to fly on the trail. Its lightweight and quick carbon frame delivers a comfortable ride, thanks to IsoBow technology, while a RockShox Reba RL fork soaks up rocks and roots with 120 mm of travel. Shifts stay clean on even your punchiest climbs thanks to a mechanical SRAM Eagle 70 transmission, and SRAM DB 6 4-piston brakes keep you stopping on a dime, when you need it.
Specifications
*spec applies to all sizes unless otherwise noted
| Frame | OCLV Mountain Carbon, IsoBow, tapered head tube, internal routing, balanced post-mount brake, Boost148 |
|---|---|
| Fork |
RockShox Reba RL, DebonAir, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel |
| Max compatible fork travel | 120 mm |
Wheels
| Wheel front | Bontrager Kovee Comp 25, Tubeless-Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
|---|---|
| Wheel rear | Bontrager Kovee Comp 25, Tubeless-Ready, 6-bolt, Boost148, 12 mm thru-axle, 29" |
| Rim Strip | Bontrager TLR |
| *Tyre | Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40" |
| Bontrager TLR sealant, 180 ml/6 oz | |
| Max tyre size | Frame: 29x2.40", Fork: See manufacturer |
Drivetrain
| Shifter | SRAM Eagle 70, 12-speed |
|---|---|
| Rear derailleur | SRAM Eagle 70, T-Type |
| *Crank |
Size: ML , M , S Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 170 mm length
|
|
Size: L , XL Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 175 mm length
|
|
| Bottom bracket | SRAM DUB, 92 mm, PressFit |
| Cassette | SRAM Eagle XS-1270, T-Type,10-52, 12-speed |
| Chain | SRAM Eagle 70, T-Type, 12-speed |
| Max. chainring size | 1x: 38T |
Components
| Saddle | Verse Short Comp, steel rails, 145 mm width |
|---|---|
| *Seatpost |
Size: S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
|
|
Size: M, ML, L Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length |
|
|
Size: XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length |
|
| *Handlebar |
Size: S Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width |
|
Size: M, ML, L, XL Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width |
|
| Grips | Trek Line Comp, nylon lock-on |
| *Stem |
Size: S Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
|
Size: M, ML Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length |
|
|
Size: L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length |
|
|
Size: XL Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
|
| Head set | FSA IS-2, 1-1/8" top, 1.5" bottom |
| Brake | SRAM DB 6 4-Piston |
| *Brake rotor | SRAM CenterLine, 6-bolt, round-edge, 160 mm |
| Rotor size | Max brake rotor sizes – Frame: 180 mm, Fork: see fork manufacturer |
Weight
| Weight | M - 11.83 kg / 26.09 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
