The Supercaliber SL 9.6 is a carbon cross-country mountain bike built for rocketing over singletrack and scorching the way to the finish line. It's built with a carbon frame that balances stiffness with compliance for power when you need it most, while IsoStrut rear suspension gives you just enough squish to soften the blow through the rough terrain peppering modern XC courses. It comes ready to rip with a 12-speed SRAM Eagle transmission, so you've got a gear for every climb and breakaway.
| Frame | SL OCLV Mountain Carbon, IsoStrut, UDH, 80 mm travel |
|---|---|
| Fork | RockShox Reba RL, DebonAir, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 110 mm travel |
| Shock | |
| Max compatible fork travel | 120 mm (533 mm axle-to-crown) |
Wheels
| Wheel front | Bontrager Kovee Comp 25, Tubeless-Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
|---|---|
| Wheel rear | Bontrager Kovee Comp 25, Tubeless-Ready, 6-bolt, Boost148, 12 mm thru-axle, 29" |
| Tyre | Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.40" |
| Max tyre size | Frame: 29x2.40", Fork: See manufacturer |
Drivetrain
| Shifter | SRAM Eagle 70, 12-speed |
|---|---|
| Rear derailleur | SRAM Eagle 70, T-Type |
| Bottom bracket | SRAM DUB, 92 mm, PressFit |
| Cassette | SRAM Eagle XS-1270, T-Type,10-52, 12-speed |
| Chain | SRAM Eagle 70, T-Type, 12-speed |
| Crank |
Size: S, M, ML
Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 170 mm length
Size: XL, L Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 175 mm length
1x: 38T, min 30T |
Components
| Saddle | Verse Short Comp, steel rails, 145 mm width |
|---|---|
| *Seatpost |
Size: S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
|
|
Size: L, M, ML Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length
|
|
|
Size: XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
|
|
| *Handlebar |
Size: S Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width |
|
Size: M, M/L, L, XL Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width |
|
| Grips | Trek Line Comp, nylon lock-on |
| *Stem |
Size: S Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
|
Size: M, ML Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
|
|
|
Size: L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
|
|
|
Size: XL Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
|
|
| Head set | FSA IS-2, 1-1/8" top, 1.5" bottom |
| Brake | SRAM DB 6 4-piston hydraulic disc |
| Rotor |
Size: S, XL, L, M, ML
SRAM CenterLine, 6-bolt, round-edge, 160 mm
Size: S, XL, L, M, ML
SRAM CentreLine, 6-bolt, round-edge, 180 mm
Max brake rotor sizes: 160mm front & rear |
Weight
| Weight | M - 12.93 kg / 28.51 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
