The Supercaliber SLR 9.8 X0 AXS is an ultra-light XC mountain bike that's built with the top components for race day. Its SLR Mountain Carbon frame is as light as it is meticulous, with a high modulus lay-up that gives you all the stiffness you crave and none of the weight. XC courses get rowdier every year, so it's equipped with a 110 mm fork and 80 mm of IsoStrut rear suspension to smooth your roll without dropping pedalling efficiency. It's all topped off with carbon wheels, a carbon cockpit and SRAM's wireless direct-mount X0 transmission.
| Frame | SLR OCLV Mountain Carbon, IsoStrut, UDH, 80 mm travel |
|---|---|
| Fork | RockShox SID Select+, DebonAir spring, Charger Race Day damper, dual remote lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 110 mm travel |
| Shock | |
| Max compatible fork travel | 120 mm (533 mm axle-to-crown) |
Wheels
| Wheel front | Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29" |
|---|---|
| Wheel rear | Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, Boost148, 12 mm thru axle, 29" |
| Tyre | Bontrager Sainte-Anne RSL XR, Tubeless Ready, dual compound, aramid bead, 220 tpi, 29x2.40" |
| Max tyre size | Frame: 29x2.40", Fork: See manufacturer |
Drivetrain
| Shifter | SRAM AXS pod w/ SRAM AXS battery pack (with charger) |
|---|---|
| Rear derailleur | SRAM X0 Eagle AXS, T-Type |
| Bottom bracket | SRAM DUB, 92 mm, PressFit |
| Cassette | SRAM Eagle XS-1295, T-Type, 10-52, 12-speed |
| Chain | SRAM X0 Eagle, T-Type, 12-speed |
| Crank |
Size: S, M, ML
SRAM X0 Eagle, DUB, 30T steel, T-Type, 55mm chainline, 170 mm length
Size: XL, L
SRAM X0 Eagle, DUB, 30T steel, T-Type, 55 mm chainline, 175 mm length
1x: 38T, min 30T |
Components
| Saddle | Verse Short Elite, hollow magnesium rails, 145 mm width |
|---|---|
| *Seatpost |
Size: S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
|
|
Size: L, M, ML Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length
|
|
|
Size: XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
|
|
| *Handlebar/stem (integrated) |
Size: S, M, ML Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 70 mm length |
| Grips | Trek Line Comp, nylon lock-on |
| Head set | FSA IS-2, 1-1/8" top, 1.5" bottom |
| Brake | SRAM Motive Silver 4-piston hydraulic disc |
| Rotor |
Size: S, XL, L, M, ML
SRAM CenterLine, 6-bolt, round-edge, 160 mm
Size: S, XL, L, M, ML
SRAM CentreLine, 6-bolt, round-edge, 180 mm
Max brake rotor sizes: 160mm front & rear |
Weight
| Weight | M - 11.38 kg / 25.09 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
