The Supercaliber SLR 9.8 is an ultralight XC mountain bike that’s ready to lay down rubber on race day. Its SLR Mountain Carbon frame is as light as it is meticulous, with a high modulus lay-up that gives you all the stiffness you crave, and none of the weight. XC courses get rowdier every year, so it's equipped with a 110 mm fork and 80 mm of IsoStrut rear suspension to smooth your roll without kicking pedalling efficiency to the wind. It's all topped off with carbon wheels, a carbon cockpit and ultra-smooth and fast shifting from a 12-speed Shimano XT Di2 wireless drivetrain.
| Frame | SLR OCLV Mountain Carbon, IsoStrut, UDH, 80 mm travel |
|---|---|
| Fork | Fox Factory 34 SL, Float EVOL air spring, GRIP SL 2- position damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt X axle, 110 mm travel |
| Shock | |
| Max compatible fork travel | 120 mm (533 mm axle-to-crown) |
Wheels
| Wheel front | Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29" |
|---|---|
| Wheel rear | Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru-axle, 29" |
| Tyre | Maxxis Aspen, Tubeless Ready, EXO casing, folding bead, 29x2.4" |
| Max tyre size | Frame: 29x2.40", Fork: See manufacturer |
Drivetrain
| Shifter | Shimano XT Di2 M8250, 12-speed |
|---|---|
| Rear derailleur | Shimano XT M8250, long cage |
| Bottom bracket | E*thirteen BB20-92 |
| Cassette | Shimano XT M8200, 10-51, 12-speed |
| Chain | Shimano Ultegra/XT M8100, 12-speed |
| Crank |
Size: S, M, ML
E*thirteen Helix Race Carbon, 34T, 55 mm chain-line, 170 mm length
Size: XL, L
E*thirteen Helix Race Carbon, 34T, 55 mm chain-line, 175 mm length
1x: 38T, min 30T |
Components
| Saddle | Verse Short Elite, hollow magnesium rails, 145 mm width |
|---|---|
| *Seatpost |
Size: S Bontrager Line Elite Dropper, 100 mm travel, MaxFlow, internal routing, 31.6 mm, 340 mm length |
|
Size: M, ML Bontrager Line Elite Dropper, 150 mm travel, MaxFlow, internal routing, 31.6 mm, 440 mm length |
|
|
Size: XL, L Bontrager Line Elite Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 480 mm length |
|
| *Handlebar/stem (integrated) |
Size: S, M, ML Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 70 mm length |
| Grips | ESI Chunky |
| Head set | FSA IS-2, 1-1/8" top, 1.5" bottom |
| Brake | Shimano XT M8200 4-piston hydraulic disc |
| Rotor |
Size: S, XL, L, M, ML
Shimano RT86, 6-bolt, 160 mm
Size: S, XL, L, M, ML
Shimano RT86, 6-bolt, 180 mm
Max brake rotor sizes: 160mm front & rear |
Weight
| Weight | M - 11.18 kg / 24.65 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
