Specifications
*spec applies to all sizes unless otherwise noted
| *Frame |
Size: XS Alpha Gold Aluminium, curved top tube, tapered head tube, internal routing, rack, mudguard and kickstand mount, UDH, Boost148, 12 mm thru axle
|
|---|---|
|
Size: M , L , S , XL Alpha Gold Aluminium, tapered head tube, internal routing, rack, mudguard and kickstand mount, UDH, Boost148, 12 mm thru axle
|
|
| *Fork |
Size: XS RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel |
|
Size: S RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel |
|
|
Size: M , L , XL RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel |
Wheels
| Hub front | Shimano TC500 alloy, CentreLock, 110x15 mm thru axle |
|---|---|
| Hub Rear | Shimano TC500 alloy, CentreLock, 148x12 mm thru axle |
| *Rim |
Size: M , XS , L , S , XL Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve |
|
Size: M , XS , L , S , XL Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve |
|
| *Tyre | |
|
Size: XS , S Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.60"
|
|
|
Size: M , L , XL Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.60"
|
|
| Rim strip | Bontrager TLR |
Drivetrain
| Shifter | Shimano Deore M6100, 12-speed |
|---|---|
| Rear derailleur | Shimano Deore M6100, long cage |
| Crank | FSA CK-220, 165 mm length |
| Chainring | FSA, 32T, steel |
| Cassette | Shimano Deore M6100, 10-51, 12-speed |
| Chain | Shimano Deore M6100, 12-speed |
| Pedal | VP-536 nylon platform |
Components
| Saddle | Bontrager Verse P3, steel rails |
|---|---|
| *Seatpost |
Size: XS , S TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length |
|
Size: M , L , XL TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length |
|
| *Handlebar |
Size: XS , S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width |
|
Size: M , L , XL Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width |
|
| Grips | Trek Line Comp, nylon lock-on |
| *Stem |
Size: XS , S Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
|
|
Size: M , L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
|
|
Size: XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length |
|
| Head set | Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8" top, 1.5" bottom |
| Brake | Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper |
| *Brake rotor |
Size: XS , S , M , L , XL Shimano RT64, CentreLock, 203 mm |
|
Size: XS , S , M , L , XL Shimano RT64, CentreLock, 203mm |
Accessories
| Battery | Bosch CompactTube 400 Wh |
|---|---|
| Charger | Bosch standard 2A, 230V, smart system |
| Motor | Bosch Active Line Plus, 50 Nm |
| Computer | Bosch Purion 200 |
Weight
| Weight | M - 21.89 kg / 48.26 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
